Wood Crusher

『Capacity』:700-4000kg/h
『Output Size』:<200mm
『Raw Material』:Wood Logs, Branches, Forks, Slabs, Bark, Bamboo...
Wood Log
Wood Plate
Wood Block
Branch
+ More
The crusher for wood integrates slicing and crushing into one, and can cut logs with a diameter of 1-30 cm. It can also be used for cutting and crushing bamboo, pine, miscellaneous wood, poplar, fir, and original bamboo materials. It is a new type of wood crushing equipment. This wood crusher is particularly suitable for processing wood chips in edible fungus culture media, fuel for power plant boilers, and bedding layers for cattle pens, etc. The discharge particle size can be adjusted according to the screen mesh size, and the discharge particle size can reach 2mm, 5mm, 8mm, 10mm, 12mm, 20mm, etc., which can meet various customer needs.
The output materials processed by this waste wood crusher can be applied to the following scenarios:
1). Can be buried on the surface to increase organic matter in the land
2). It can improve the soil and is a good organic fertilizer.
3). Can be used as feed for herbivorous animals.
4). It can be used as the base material for edible fungus cultivation.
5). Can be used as potting soil filler.
6). It can be used as raw material for pulp and artificial board.
7). Can be used as biofuel. Covering bare soil prevents dust and suppresses weed growth.
Features and Benefits:
This timber wood crusher has reasonable design, compact structure, safety, durability, high production efficiency and good crushing effect. The whole set of waste wood crusher is driven by only one motor, which has the advantages of low noise, low price, stable working performance, low energy consumption, high output, good quality of finished wood chips, and low processing cost.
Model | SS-420 | SS-500 | SH-600 | SH-700 | SH-800 | SH-1000 | SH-1200 |
Cutter Dia. (mm) | 400 | 450 | 550 | 650 | 750 | 950 | 1150 |
Hammer No. (pcs) | 4 | 4 | 4 | 4 | 4-8 | 4-8 | 4-8 |
Blade Size (mm) | 90*60*10 | 120*80*10 | 150*80*10 | 180*80*10 | 230*90*10 | 260*90*10 | 280*90*10 |
Hammer No. (pcs) | 12 | 16 | 22 | 26 | 30 | 40 | 50 |
Inlet Port (mm) | 150*150 | 180*180 | 200*200 | 230*230 | 250*260 | 280*320 | 360*360 |
Rotating Speed(r/min) | 650 | 650 | 680 | 650 | 650 | 600 | 550 |
Motor Power (kw) | 7.5-11 | 11-15 | 15-18.5 | 18.5-22 | 30-37 | 45-75 | 75-110 |
Capacity (kg/h) | 400-500 | 600-800 | 1000-1500 | 2000-2500 | 2500-3000 | 3000-4000 | 4000-5000 |
Diesel Engine Power(HP) | single-cylinder 15 | single-cylinder 18 | single-cylinder 22 | single-cylinder 35 | 4100 supercharge | 4108 supercharge | 6105 supercharge |
